OVERVIEW
The YOKI OP-V500 is a professional three-display LED wheel balancer based on the supplier V50 platform. Automatic diameter and distance measurement reduces manual setup, while automatic width measurement is available as an optional configuration.
ALU-S electronic measuring-arm guidance and laser positioning support adhesive-weight placement on alloy wheels. Dynamic, static and multiple ALU programmes cover everyday passenger-vehicle balancing, with split and hidden-weight functions available for a cleaner finish.
THREE-DISPLAY CONTROL PANEL
WORKSHOP BENEFITS
Automatic diameter and distance input speeds up routine wheel setup.
Three LED displays keep wheel data and balancing results easy to read.
ALU-S guidance and laser positioning assist accurate adhesive-weight installation.
Self-diagnosis and self-calibration support routine machine checks.
The rigid steel cabinet and extended drive shaft support stable operation and practical wheel access.
PRODUCT DETAILS
Three LED balancing displays.
Automatic wheel diameter and distance measurement.
Dynamic, static, ALU and ALU-S balancing modes.
Split and hidden adhesive-weight functions.
Laser guidance for adhesive-weight placement.
EXTENDED DRIVE SHAFT
SPECIFICATIONS
Maximum wheel diameter: 1,100 mm (44 in)
Maximum wheel weight: 70 kg (154 lb)
Rim diameter range: 254-610 mm (10-24 in)
Rim width range: 38-508 mm (1.5-20 in)
Machine weight: 101 kg
Power supply: Contact YOKI to confirm the required electrical configuration.
OPTIONAL EQUIPMENT
Automatic wheel-width measuring arm
Electromagnetic positioning brake with LED work light
Wheel guard control
Motorcycle wheel adaptor
Isuzu light-truck cone
Toyota Prado cone
OPTIONAL AUTOMATIC WIDTH MEASUREMENT
APPLICATIONS
Passenger vehicle wheel balancing
Tyre service, mechanical repair and general automotive workshops
Alloy wheel balancing and adhesive-weight applications
Supplied and supported in Australia by YOKI Auto Equipment. Contact YOKI to confirm availability, electrical configuration and suitability for your workshop.
