OVERVIEW
The YOKI OP-1500 Pro combines a swing arm tyre changer with independently controlled left and right assist arms. It adds bead support and tyre-lifting assistance to the OP-1500 working layout.
The right-side adjustable rubber pressing wheel assists mounting and demounting, while the left-side arm helps lift the tyre and separate the lower bead. This arrangement gives the operator more control over bead position during fitting.
FEATURES
Swing arm layout with independently controlled left and right assist arms
Adjustable rubber tyre-pressing wheel on the right arm
Tyre-lifting and lower-bead assistance on the left arm
Tempered-steel mounting head and octagonal turntable
Heat-treated clamping jaws and twin clamping cylinders
Multi-angle adjustable bead-breaker shovel
PRODUCT DETAILS
The 13 mm thick chuck assembly has fine adjustment of the jaw opening and closing range. The jaws can be positioned to suit the wheel being clamped.
The foot-operated pneumatic valve uses S304 stainless-steel piston rods for corrosion resistance. Its drawer-style control unit provides access for maintenance and repair.
The right assist arm has a movable, adjustable rubber pressing wheel. The original model description specifies assistance for tyres above 13 inches; confirm compatibility with the wheel and tyre combination being serviced. A limit-stop controls the working distance between the pressing wheel and rim.
The left assist arm combines tyre-lifting support with lower-bead separation assistance. Independent control of the two arms allows bead-height adjustment during mounting.
SPECIFICATIONS
Model: YOKI OP-1500 Pro
External rim clamping: 10-22 in
Internal rim clamping: 12-24 in
Maximum wheel width: 16 in
Maximum wheel diameter: 1,120 mm (44 in)
Working air pressure: 8-12 bar
Power supply: 240 V
Main package (L x W x H): 1,165 x 805 x 920 mm
Main package weight: 230 kg
Additional package (L x W x H): 1,050 x 370 x 320 mm
Additional package weight: 45 kg
Dimensions above describe freight packaging, not the installed machine footprint.
APPLICATIONS
Tyre fitting shops and mechanical workshops wanting swing arm operation with additional bead and tyre-handling assistance.
For wheel and tyre compatibility, supplied accessories and workshop setup requirements, contact YOKI Auto Equipment. Use the model-specific operating instructions and suitable operator training.
