OVERVIEW
The YOKI OP-1900 is a tilt-back tyre changer with pneumatic horizontal and vertical arm locking. The rear-tilting column moves clear of the turntable to provide access for positioning the wheel.
Its reinforced cabinet and column construction, adjustable bead-breaker shovel and fine-adjustable clamping assembly are designed for routine professional tyre service.
FEATURES
Tilt-back column
Pneumatic horizontal and vertical arm locking
Fine-adjustable turntable clamping jaws
Multi-angle adjustable bead-breaker shovel
Dual-inlet bead-breaker cylinder
Welded column base and modular steel cabinet
PRODUCT DETAILS
The 14 mm thick chuck assembly has fine adjustment of the jaw opening and closing range. The jaws can be positioned to suit the wheel being clamped.
The rear-tilting upright arm opens the working area above the turntable. Its sliding roller mechanism uses a precision-ground 55 x 55 mm square push-pull arm.
The modular cabinet uses CNC-formed steel panels and concealed welded seams. The column base and cabinet are welded together, with a tapered bushing and bi-directional locking arrangement supporting the column connection.
The foot-operated pneumatic valve uses S304 stainless-steel piston rods for corrosion resistance. Its drawer-style control unit provides access for maintenance and repair.
The motor has an aluminium housing and copper windings. The bead-breaker assembly uses a sealed, dual-inlet cylinder.
SPECIFICATIONS
Model: YOKI OP-1900
External rim clamping: 10-24 in
Internal rim clamping: 12-26 in
Maximum wheel width: 16 in
Maximum wheel diameter: 1,120 mm (44 in)
Working air pressure: 8-12 bar
Power supply: 240 V
Main package (L x W x H): 1,165 x 805 x 1,020 mm
Main package weight: 325 kg
Dimensions above describe freight packaging, not the installed machine footprint.
APPLICATIONS
Professional tyre fitting bays and general service workshops using a tilt-back tyre changer.
For wheel and tyre compatibility, supplied accessories and workshop setup requirements, contact YOKI Auto Equipment. Use the model-specific operating instructions and suitable operator training.
