YOKI OP-Master 9220 Leverless Centre Clamping Tyre Changer
YOKI OP-Master 9220 leverless centre clamping tyre changer
$8,500 AUD inc. GST
Tyres up to 1,120 mm diameter; rim range 10-26 in
Pneumatic wheel lift and positioning device
110V 1PH / 220V 1PH or 3PH / 380V 3PH
Space-saving leverless tyre changer with centre clamping and assist arms.
OVERVIEW
The YOKI OP-Master 9220 is a leverless centre-clamping tyre changer designed for professional workshops that need full assist-arm capability in a more space-efficient layout. Its spiral-lift side-swinging upright arm moves clear of the working area while reducing the machine's floor-space requirement.
The pneumatic duck-head assembly, 125 mm bidirectional assist-arm cylinder, telescopic tyre-press roller and wheel lift provide controlled support for premium rims, low-profile tyres and high-volume passenger-vehicle tyre service.
WORKSHOP BENEFITS
The side-swinging upright arm preserves workshop floor space and opens access around the wheel.
Pneumatic assist arms help control the tyre bead during mounting and demounting.
The 180-degree rotating tyre-press arm can approach the wheel from multiple working angles.
A pneumatic wheel lift raises, rotates and positions the wheel to reduce manual lifting.
PRODUCT DETAILS
Spiral-lift side-swinging upright arm
55 x 55 mm high-strength push-and-pull square arm
Third-generation pneumatic flip demounting head
125 mm bidirectional auxiliary-arm cylinder
Pneumatic telescopic tyre-press roller and rotating press arm
Multi-angle adjustable bead-separation shovel
Pneumatic wheel lifting and positioning device
UPRIGHT AND ASSIST-ARM LAYOUT
The side-swinging upright is designed to open access around the wheel while limiting the machine floor-space requirement. The square tool arm and pneumatic head are arranged beside the auxiliary-arm assembly.
Upright, tool-arm and assist-arm arrangement.
PNEUMATIC BEAD ASSISTANCE
The 125 mm bidirectional auxiliary-arm cylinder supports the pressing tools. A telescopic tyre-press roller and rotating arm provide assistance from different positions around the wheel.
Pneumatic assist cylinder and pressing tools.
CENTRE-CLAMPING WORK AREA
The centre-clamping platform holds the wheel at the hub while the pneumatic head and assist tools work around the tyre. The multi-angle bead-breaker shovel supports the bead-separation task.
Centre-clamping platform and bead-handling equipment.
PNEUMATIC WHEEL HANDLING
The pneumatic lifting device assists raising, rotating and positioning the wheel. The sequence illustrates the handling arrangement without replacing the operating manual or operator training.
Wheel-lifting and positioning views.
DESIGN AND WORKSHOP DETAILS
The 55 x 55 mm square push-pull arm supports the pneumatic demounting head. The telescopic pressing roller and 180-degree rotating press arm provide bead assistance from several positions.
A 125 mm bidirectional assist-arm cylinder supports the pneumatic handling system. The wheel lift assists lifting, rotation and positioning rather than relying on manual handling alone.
The welded column base and cabinet, 4 mm steel-panel chassis and multi-angle adjustable bead-breaker shovel support the machine working layout.
SPECIFICATIONS
Working air pressure: 8-12 bar
Maximum tyre width: 406 mm (16 in)
Maximum tyre diameter: 1,120 mm (44 in)
Rim width range: 38-508 mm (1.5-20 in)
Rim diameter range: 254-660 mm (10-26 in)
Motor power: 220V 1.1 kW / 380V 0.75 kW
Power supply: 110V 1PH / 220V 1PH or 3PH / 380V 3PH
Net / gross weight: 450 / 540 kg
SUPPLIED ACCESSORIES
Supplier-listed standard accessories include a hub-locking shaft, cone and duck-head protective cases, BMW and Prado cones, and a plastic crowbar. A tyre clip and hub reverse fixture are shown as optional equipment.
APPLICATIONS
Passenger-vehicle tyre service
Low-profile and premium wheel tyre fitting
Tyre shops requiring assist-arm capability with a compact footprint
Supplied and supported in Australia by YOKI Auto Equipment. Contact YOKI to confirm stock availability, electrical configuration and suitability for your workshop.
