OVERVIEW
The YOKI OP-Master 9850 is a PLC-controlled, zero-contact tyre changer for advanced passenger-vehicle and premium-wheel service. Its built-in memory stores the initial positions of the demounting head and tyre-pressure arm, helping shorten setup time for the next operation.
An electric linear-drive wheel-clamping spindle, range-extending pressure arm and synchronised mounting-head system provide precise control while keeping the tool path aligned with the wheel centre.
WORKSHOP BENEFITS
PLC position memory supports a faster repeat workflow after the initial machine setup.
The electric clamping spindle allows safe, precise adjustment of the distance between the wheel hub and mounting head.
The control panel and foot pedals are positioned on the same side for a more ergonomic operating station.
The pneumatic hook and synchronised pressure arm maintain a zero-contact working path to help protect the rim during mounting and demounting.
PRODUCT DETAILS
PLC memory for demounting-head and pressure-arm positions
Range-extending tyre-pressure arm for precise release-disc positioning
Manually adjustable wheel-clamping spindle height
Electric linear-drive wheel-clamping spindle
Same-side control panel and foot-pedal layout
Zero-contact pneumatic-hook tyre removal system
Mechanically synchronised mounting head and tyre-pressure arm
PLC CONTROL AND POSITION MEMORY
The PLC system stores the initial positions of the demounting head and tyre-pressure arm. The control panel and foot controls are positioned on the same side of the machine for a consolidated operating station.

Control panel, upright and upper tool arm.
ELECTRIC CLAMPING SPINDLE
The electric linear-drive wheel-clamping spindle provides controlled movement when setting the relationship between the wheel hub and mounting head. The spindle height can also be adjusted manually.

Wheel-clamping spindle and lower tool assembly.
WHEEL SUPPORT AND BEAD TOOLS
The wheel-support bracket and tool arms move together. Mechanical synchronisation keeps the working tools directed towards the wheel centre during the tyre service operation.

Mounted wheel, support bracket and bead-handling tools.
COORDINATED MOUNTING AND DEMOUNTING
The pneumatic hook, mounting head and pressure-arm system coordinate bead handling around the wheel. These supplier views illustrate the mechanism; suitability and operation must follow the model-specific instructions.

Coordinated tool movement around the wheel.
DESIGN AND WORKSHOP DETAILS
An integrated rear storage shelf keeps equipment close to hand. The control panel includes a mounting-head height memory function for repeat jobs.
The electrically driven clamping table provides controlled rim-position adjustment, with a central locking arrangement for clamping and release.
The tool arms and tyre-support bracket move together, with mechanical synchronisation keeping the tools directed towards the wheel centre.
SPECIFICATIONS
Maximum tyre width: 406 mm (16 in)
Maximum tyre diameter: 1,270 mm (50 in)
Rim width range: 38-508 mm (1.5-20 in)
Rim diameter range: 254-660 mm (10-26 in)
Motor inverter power: 220V 1.5 kW
Power supply: 110V 1PH / 220V 1PH
Net / gross weight: 525 / 625 kg
Packing size: 1,400 x 1,200 x 1,860 mm
SUPPLIED ACCESSORIES
Supplier-listed accessories include a quick-locking nut, duck-head and cone protective cases, plastic crowbar, BMW cone and locating pin.
APPLICATIONS
Premium passenger-vehicle tyre service
Low-profile and high-value wheel applications
High-volume tyre shops and specialist wheel-service workshops
Supplied and supported in Australia by YOKI Auto Equipment. Contact YOKI to confirm stock availability, electrical configuration and suitability for your workshop.
